FINISHED PARTS & PLAIN BEARINGS

CUSTOM PLAIN BEARINGS MADE TO YOUR DRAWING

Machining Processes

Do you need a plain bearing bushing, a sliding ring, a slide plate or another sliding element with special dimensions?
Bornebusch manufactures plain bearings and sliding elements according to your drawing, your sample or your technical specifications. Modern CNC machining allows us to produce geometries, bores, grooves, fits and other design features with precision.
Depending on the component and its requirements, the machining processes we use include:

• CNC turning
• CNC milling
• Machining of grooves and bores
• Production of custom fits and contours
• Splitting of bushings, split plain bearings

The result is a ready-to-install plain bearing that can be used directly in its intended application.

WHICH PLAIN BEARINGS ARE MADE TO DRAWING?

Designs & Sliding Elements

Bornebusch manufactures a variety of designs and sliding elements to customer specifications. These include, for example:

• Plain bearing bushings
• Flanged bushings
• Sliding rings
• Slide plates
• Sliding strips
• Thrust washers
• Self-lubricating plain bearings
• Sliding elements with solid lubricant
• Custom parts made to drawing

Special dimensions outside common standard sizes can also be produced individually, depending on material, geometry and technical feasibility.

PLAIN BEARINGS MADE OF BRONZE AND OTHER NON-FERROUS METALS

Material Expertise

The choice of material is crucial for the load capacity, wear behavior and service life of a plain bearing.

Bornebusch has many years of experience with bronzes, gunmetal, brass and other non-ferrous metals. This allows material and machining to be matched to the later application right from the planning stage.

Various bronze alloys are suitable for highly loaded bearing points in particular. Which alloy is the right one depends on factors such as load, type of motion, temperature, ambient conditions and the intended lubrication.

On request, Bornebusch will help you select a suitable material for your planned plain bearing.

SELF-LUBRICATING PLAIN BEARINGS TO CUSTOMER SPECIFICATIONS

WABRO® Sliding Elements

For applications with medium to high loads at low sliding speeds, Bornebusch offers self-lubricating, maintenance-free sliding elements with WABRO^®.
Solid lubricants are inserted into bores or grooves. During movement, the lubricant is released onto the sliding surface, where it forms a stable lubricating film.

WABRO^® sliding elements can also be machined ready for installation to customer specifications and are suitable for applications where regular relubrication is difficult or not desired, among others.

PLAIN BEARINGS AS SINGLE PARTS OR IN SERIES

Quantities

Not every drawing automatically means series production. That is why Bornebusch manufactures both individual single parts and production runs of various sizes. Depending on the component, options include:

• One-off production
• Spare parts
• Prototypes
• Small series
• Medium series
• Large series

This makes our manufacturing suitable for mechanical and plant engineering as well as for spare parts requirements, maintenance and industrial series applications.

WHICH APPLICATIONS?

Fields of Application

Custom-made plain bearings are used wherever standard dimensions or standard materials are not sufficient. Typical fields of application include:

• Mechanical engineering
• Plant engineering
• Machine tool manufacturing
• Special-purpose machinery
• Steel and rolling mill construction
• Conveyor technology
• Maintenance and spare parts supply

Which design and which material make sense always depends on the specific operating conditions at the bearing point.

FROM SEMI-FINISHED PRODUCT TO FINISHED PLAIN BEARING

Everything from a Single Source

One advantage of manufacturing with Bornebusch is the combination of material expertise and mechanical machining.

Instead of splitting material procurement and CNC production between different suppliers, Bornebusch can handle several steps within one project:

Material selection → Semi-finished product → Cutting → CNC machining → Quality control → Ready-to-install plain bearing

This reduces interfaces and coordination effort. At the same time, material, dimensions and machining can be aligned with each other at an early stage.

PRECISE CNC MANUFACTURING AND QUALITY CONTROL

Quality

With a plain bearing, fits, surfaces and dimensional accuracy determine how well it will perform later on.

That is why Bornebusch relies on modern CNC turning and milling technology as well as continuous monitoring of dimensional accuracy during production. Quality control is further supported by modern 3D measuring technology, among other methods.

This allows even complex parts made to drawing to be produced reproducibly and with consistent quality.

HOW DOES THE MANUFACTURING PROCESS WORK?

Your Inquiry in 3 Steps

To process your inquiry, we first need your technical drawing or the key details of the component you require. The following information is particularly helpful:

1. Drawing or sample
   Send us your existing technical drawing, CAD data or a sample part.
2. Material
   If the desired material has already been specified, we can take it into account directly. Alternatively, we will work with you to determine suitable materials.
3. Dimensions and tolerances
   Inner and outer diameters, length, bores, grooves, fits and other relevant dimensions are manufactured according to your specifications.

Depending on geometry and material, plain bearings can be manufactured in sizes from 5 mm to 2,500 mm.

Can Bornebusch manufacture plain bearings based on an existing drawing?

Yes. Bornebusch manufactures plain bearings, sliding elements and other CNC components according to technical drawings, samples and individual customer specifications.

Can single plain bearings be manufactured as well?

Yes. In addition to small, medium and large series, we also produce single parts and spare parts.

Are self-lubricating plain bearings made to drawing also available?

Yes. With WABRO^®, Bornebusch offers self-lubricating sliding elements that can be machined ready for installation to customer specifications.

Which materials can be used for custom-made plain bearings?

Our range of materials includes various bronze alloys, gunmetal, brass, copper alloys and other non-ferrous metals. The choice depends on the design and the operating conditions.

Can plain bearings be delivered ready for installation?

Yes. Bornebusch can fully machine parts made to drawing and deliver them ready for installation.

Can Bornebusch help with selecting the material?

Yes. Thanks to many years of experience with non-ferrous metals and plain bearing applications, Bornebusch can advise customers on choosing suitable materials and designs.
